UniView MW3565-U-CA 65 inch smart Interactive Display, 4K UHD Resolution, Android 11, 8ms Response Time, 4GB RAM & 32GB Storage, 2 Touch Pens with Warranty | MW3565-U-CA
Estimated delivery within UAE 1–2 working days
Delivery to other countries 3–5 working days
- Brand : UNV
- Model : MW3586-U-CA
- Size: 65 inches
- Resolution: 3840 x 2160 (4K)
- Response Time: 8 ms
- RAM: 4 GB DDR4;Storage: 32 GB eMMC
- Operating System: Android 11.0
- Camera : 13 MP (4160 x 3120)
- Warranty : 3 Years
UniView MW3565-U-CA 65 inch smart Interactive Display, 4K UHD Resolution, Android 11, 8ms Response Time, 4GB RAM & 32GB Storage,
Brand : UNV
Model : MW3565-U-CA
Panel Features
Size: 65 inches
Resolution: 3840 x 2160 (4K)
Brightness: 350 cd/m²
Contrast Ratio: 1200:1
Response Time: 8 ms
Color Support: 1.07 billion colors
Viewing Angle: 178° (H/V)
Backlight: DLED
Android System
CPU: Amlogic T982 (4 x A55, Mali G52 GPU)
Frequency: 1.9 GHz
RAM: 4 GB DDR4
Storage: 32 GB eMMC
Operating System: Android 11.0
Touch Technology
Control Type: Contactless IR sensor (20-point touch)
Precision: ±1 mm
Recognizable Object Size: 3 mm (5 points)
Glass: 4 mm tempered, anti-glare, Mohs hardness level 7
Touch Response Time: ≤ 10 ms
Interface Options
Video Inputs: 3 x HDMI IN (4K), 1 x AV IN, 1 x DP IN, 1 x VGA IN, 1 x YPbPr IN
Video Outputs: 1 x AV OUT, 1 x HDMI OUT (4K)
Audio Inputs: 1 x MIC IN
Audio Outputs: 1 x Earphone, 1 x Coaxial
USB Ports: 3 x USB 3.0, 1 x USB 2.0, 1 x Touch USB, 1 x Type-C, 1 x TF Card
Network: 1 x LAN IN/OUT, 1 x RS232
Audio Specifications
Speakers: 15W treble + 115W bass (per channel)
Camera Features
Resolution: 13 MP (4160 x 3120)
Video Frame Rates: 13MP@15fps, 4K@30fps, 1080P@30fps, 720P@30fps
Field of View: 118° (D), 94° (H), 75° (V)
Microphone
Count: 8 microphones
Pickup Range: 8 m
Connectivity
Wi-Fi: Supports Wi-Fi 5 & 6 (5/2.4 GHz), coverage up to 30 m², 20 m transmission distance
Bluetooth: Version 5.2, 10 m transmission distance
General Specifications
VESA Mounting: 500 x 400 mm
Input Voltage: AC 100-240V, 50/60Hz
Power Consumption: 188.3W (normal), < 0.5W (standby)
Operating Conditions:
Temperature: 0°C to 50°C
Humidity: 10% to 90% RH (non-condensing)
Storage Conditions:
Temperature: -20°C to 60°C
Humidity: 0% to 95% RH (non-condensing)
Dimensions:
Product: 1490 x 892 x 689 mm
Package: 1615 x 1055 x 205 mm
Weight:
Net: 41.4 kg
Gross: 45.7 kg
Included Accessories
1 x Power cable
2 x Stylus
1 x Quick guide
1 x Wireless infrared remote control
1 x Wall mount bracket
