UNIVIEW MW3586-U-X UNV 86Inch 4K Smart Interactive Display, 8GB RAM, 128GB Storage, Builtin 4K Camera, 350 nits Brightness, 32-point touch, inbuilt Wi-Fi, 15W x 2 speaker, Android 13, Google Playstore supported

متوفر في المخزن

Warranty: عام واحد

رمز المنتج

UNV MW3586-U-X

7٬299٫00 د.إ.‏

Original 100% Visit Store →

انتقل إلى النهاية معرض الصور

main product photo

تخطي إلى بداية معرض الصور

المزيد من المعلومات

86" 4K UHD anti-glare display with 3840x2160 resolution and 350 cd/m² brightness.
Zero lamination tech reduces refraction for better visuals.
Android 13.0 OS with Amlogic T982 quad-core CPU, 8GB RAM, and 128GB storage.
Infrared touch supports 32-point touch and 20-point writing on 4mm tempered glass.
Bluetooth 5.0 and dual-band Wi-Fi (5G/2.4G) with up to 30m² coverage.
Multiple inputs: HDMI, VGA, AV, DP; Outputs: AV, HDMI, audio.
Audio: 2 x 15W speakers for rich sound.
Supports multi-language OSD with 23 languages.
Dimensions approx. 1970 x 1151 x 116 mm; power 236 W.
Includes remote, touch pens, wall mount, and antennas.

Manufacturer: UNV

Model: UNV MW3586-U-X

Colour: اسود

Warranty: عام واحد

Dimensions: 2085 x 1276 x 220

Weight: 79.000000

UNIVIEW MW3586-U-X UNV 86Inch 4K Smart Interactive Display, 8GB RAM, 128GB Storage, Builtin 4K Camera, 350 nits Brightness, 32-point touch, inbuilt Wi-Fi, 15W x 2 speaker, Android 13, Google Playstore supported

Specifications

Panel Description

Panel Size: 86"
Resolution: 3840 x 2160
Brightness: 350 cd/m²
Contrast Ratio: 1200:1
Response Time: 8 ms
Color Support: 8-bit + FRC
Viewing Angle (H/V): 178°/178°
Refresh Rate: 60 Hz
Color Gamut: 72%
Lifespan: 50000H
Surface Hardness: 9H (7 on Mohs scale)
Haze Value: 25%
Display Size (mm): 1895.04 x 1065.96
Pixel Pitch (H x V) (mm): 0.49 x 0.49

System Description

CPU: Amlogic T982 quad-core A55
CPU Frequency: 1.9 GHz
RAM: DDR4, 8GB
ROM: eMMC, 128GB
Android Version: 13.0

Camera

Pixel: 16MP
Android: 8MP (Photos), 2MP (Video)
Windows: 16MP (Photos and Video)
Microphone Array: 8
Pickup Distance: 8

Touch Description

Touch Control: Supports 32-point touch, 20-point writing
Touch Precision: 1 mm
Recognizable Object: 5 points, 3 mm
Touch Response Time: ≤5 ms
Glass: 4mm tempered glass, 7H (Mohs), anti-glare
Touch Technology: Infrared touch

Audio Description

Speaker: 2.0 sound channel
Left Channel: 1 x 15W, 8Ω
Right Channel: 1 x 15W, 8Ω

Wi-Fi Description

Wi-Fi Configuration: Supports 5G / 2.4G
Wi-Fi Performance: 30m² coverage, 20m transmission distance in open space

Bluetooth Description

Bluetooth Version: 5.0

OSD Description

Multi-Language Support: 23 languages including Simplified Chinese, Traditional Chinese, Japanese, German, English, Spanish, French, Italian, Portuguese, Russian, Korean, Vietnamese, Ukrainian, Hungarian, Polish, Thai, Arabic, Kazakh, Bulgarian, Galician, Catalan, Uzbek, Indonesian

Interface Description

Video Input: 3 x HDMI IN (4K), 1 x VGA IN, 1 x AV IN, 1 x YPbPr IN, 1 x DP IN
Video Output: 1 x AV OUT, 1 x HDMI OUT (4K)
Audio Input: 1 x MIC_IN
Audio Output: 1 x Earphone, 1 x Coaxial audio output (COAX)
Other Interfaces: 1 x RS232, 3 x front USB 3.0, 1 x on-board USB 2.0, 1 x on-board USB 3.0, 2 x TOUCH USB, 1 x Type-C, 1 x TF Card
Network: 1 x LAN OUT, 1 x LAN IN

General Description

Operating Voltage: AC 100V to 240V, 50/60 Hz
Overall Power Consumption: 236 W
Operating Temperature: 0°C to 50°C
Operating Humidity: 10% to 90% RH (non-condensing)
Product Dimensions (W x H x D): 1969.8 x 1151 x 115.9 mm
Package Dimensions (W x H x D): 2085 x 1276 x 220 mm

Accessories Included

1 x Power cable
2 x Touch pens
1 x Quick guide
1 x Wall mount bracket
1 x Infrared remote control
5 x Rod antenna
