Hikvision DS-KIS603-P Video Intercom Villa Door Station Bundle, 7-inch Colorful Touch Screen (1024 × 600 Resolution), Supports Wireless Network, Standard PoE

In Stock

Warranty: 1 Year

SKU

DS-KIS603-P

KWD 47.55

Original 100% Visit Store →

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

More Information

Villa Door Station，standard PoE， 2 MP HD camera.Noise suppression and echo cancellation， low illumination.
Network Indoor Station.7-inch colorful touch screen with resolution 1024 × 600 .
Stores messages and captured pictures in the TF card.Remote unlocking via the client software or the mobile client.
Access control functions, Tamper-proof.Configuration remotely via Web.
Access control functions, Tamper-proof.Configuration remotely via Web.

GTIN: 757277599729

Manufacturer: HikVision

Model: DS-KIS603-P

Colour: Multi

Dimensions: 200 mm × 140 mm × 15.1 mm

Weight: 1.000000

Warranty: 1 Year

Door Station Specifications

System Parameters

Operating System: Embedded Linux
Flash: 32 MB
RAM: 128 MB

Video Parameters

Camera: 2MP HD Camera
Night Vision: Low illumination IR supplement mode (3m)
Backlight Compensation: Supported
Digital Noise Reduction: Supported
Wide Dynamic Range (WDR): True WDR
Field of View:
- Horizontal: 129°
- Vertical: 75°
Video Compression Standard: H.264
Stream:
- Main Stream: 1080p@30fps, 720p@25fps
- Sub Stream: D1@25fps
Motion Detection: Supported
Flash-Avoid Frequency: 50 Hz, 60 Hz

Audio Parameters

Audio Input: Built-in Omnidirectional Microphone
Audio Output: Built-in Loudspeaker
Audio Quality: Noise Suppression and Echo Cancellation
Audio Compression Standard: G.711 U
Audio Compression Rate: 64 Kbps
Audio Intercom: Two-way Audio Communication

Network Parameters

Network Protocols: TCP/IP, RSTP
Wired Network: 10/100 Mbps Ethernet

Device Interfaces

RS-485: 1
Alarm Input: 4
Debugging Port: 1
Grounding: 1
TAMPER Switch: 1

General

Power Consumption: < 10 W
Working Temperature: -40°C to 53°C (-40°F to 127.4°F)
Working Humidity: 10% to 95%
Dimensions: 138 mm × 65 mm × 27 mm
Installation: Surface Mounting
Protection Level: IP65
Indicators: 2
Power Supply: IEEE802.3af, Standard PoE, 12 VDC

Indoor Station Specifications

System Parameters

Operating System: Embedded Linux
Memory: 128 MB
Flash: 32 MB

Display Parameters

Display Screen: 7-inch Color TFT
Display Resolution: 1024 × 600
Operation Method: Capacitive Touch Screen

Audio Parameters

Audio Input: Built-in Omnidirectional Microphone
Audio Output: Built-in Loudspeaker
Audio Quality: Noise Suppression and Echo Cancellation
Audio Compression Standard: G.711 U
Audio Compression Rate: 64 Kbps

Network Parameters

Wired Network: 10/100 Mbps Self-Adaptive
Wireless Network: Wi-Fi 802.11 b/g/n
Protocol: TCP/IP, SIP, RTSP
RS-485: 1
RJ-45: 10/100 Mbps Self-Adaptive

Device Interfaces

RS-485: 1
Alarm Input: 8-channel Alarm Inputs
Relay Output: 2
TF Card: Max 32 GB, SD 2.0 or lower version

General

Power Consumption: ≤ 6 W
Working Temperature: -10°C to 55°C (14°F to 131°F)
Working Humidity: 10% to 90%
Dimensions (L x W x H): 200 mm × 140 mm × 15.1 mm (7.9" × 5.5" × 0.6")
